5L HDPE blow moulding machine
Susan Zhong
Contact person
Basic Information
5L HDPE blow moulding machine(TCY601T) is designed for blowing 5L container with view strip line Good quality and best price can make your needs D means double station Y means two-way guide rail clamping structure 1 means number of die-head Voltage: 380V/50HZ Specifications TCY601TMaterial HDPE, LDPE, PP, etcMax container capacity L5Number of die set1Machine Dimension(L×W×H) M3.5x2.2x2.8Weight ton5.5Clamping UnitClamping force KN70Platen opening stroke mm188-538Platen size mm338x450Max mould size(W×H) mm360x450Mould thickness mm190-300PowerMax total power KW20.5Total power KW33.9Fan power for screw KW0.3Air pressure Mpa0.7Air consumption m³/min0.9Average energy consumption KW12.5Extruder unitScrew diameter mm60Screw L/D ratio L/D25Plasticizing capacity Kg/hr60Number of heating zone zone3Extruder heating power KW8.8Extruder driving power KW15Extruder for view strip lineScrew diameter mm25Extruder heating power KW3.5Extruder driving power KW1.5DieNumber of heating zone zone3Power of die heating KW4.6Max die-pin diameter mm145
Delivery terms and packaging
Packaging Detail: 5L HDPE blow moulding machinePacking:Iron Tray and Film Delivery Detail: 30 Work Days
Port: Shanghai
