Automatic Extrusion Blow Molding Machine
Susan Zhong
Contact person
Basic Information
Automatic Extrusion Blow Molding Machine Good quality and best price can make your needs TCY70Dseries: TCY701D/TCY702D/ TCY703D/ TCY704D D means double station Y means two-way guide rail clamping structure 1, 2, 3, 4 means number of die-head Voltage: 380V/50Hz SpecificationsTCY701DMaterialHDPEMax container volumeL5Number of dieSet1Number of stationSet2Output(dry Cycle)Pc/hr500*2Dimension(L*W*H)M3.53*2.25*2.6WeightTon7.5Clamping UnitClamping forceKN70Platen opening strokeMM188-538Platen sizeMM338*430Max mould size(W*H)MM360*450Mould thicknessMM190-320PowerMax driveKW27.5Total powerKW47.5Fan power for screwKW0.48Air pressureMpa0.7Air consumptionm³/min0.9Average energy consumptionKW23Extruder systemScrew diameterMM70Screw L/D ratioL/D24Plasticizing capacityKg/hr70Number of heating zoneZone3Extruder heating powerKW14.2Extruder driving powerKW22Die headNumber of heating zoneZone3..5Power of die heatingKW5.7Max die-pin diameterMM150
Delivery terms and packaging
Packaging Detail: Automatic Extrusion Blow Molding MachinePackage:Iron tray and fim Delivery Detail: 30workdays
Port: Shanghai
Payment term
Letter of credit
Telegraphic transfer
-
Payment Methods
We accept:
